MONOLITHIC
CONTACTS
1NO
1
1NC
2
1NO + 1NC
3
1NC + 1NO
4
2NC
5
2NO
6
DESCRIPTION
NON-SPRING RETURN 30°
NON-SPRING RETURN
SPRING RETURN LEFT HAND
SPRING RETURN 30°
SPRING RETURN
SPRING RETURN RIGHT HAND
DIMENSIONS
TECHNICAL SPECIFICATIONS
Integral Contacts
UTILIZATION CATEGORY
SUPPLY
IEC – 60947-5-1U
L-508I
TH/THERMAL CURRENT
AC
AC-15
A600
10A
DC
DC-13
P300
Contact
NO and NC
Rated Voltage
230V AC
120V AC
24V AC
Rated Current
6A
6A
1.5A
Frequency
50-60 Hz
Electrical Life for Contact
2.5KV (All terminal shorted togheter)
HV Test for 60 Sec
0.5 Million Cycle
Rated insulation Voltage
600 VAC
Terminals
Suitable for flexible or solid conductors from 2×1 mm2 or 2×2.5 mm2
Current Carrying Material
Brass
Contact Type
Make & Break
Contact Material
AgNi
Insulation Resistance at 500 VDC
50 M Ø
Operating Torque
0.8 Nm
Contact Resistance
20 M Ø
MV drop at 16 A DC
200 MV
Type
Non Illuminated
Function
Push, Push-Push, Push Turn, Selector
Colour
Red / Green / Black / Yellow / White / Blue / Amber
Disposition of Contacts
